Size: 955 * 690 * 400 mm
Operating speed: 0-5.5Km/h
Chassis weight (with shell): 139KG
Chassis weight (excluding shell): 120KG
Ground clearance: 125 ± 15mm (depending on load capacity)
Protection level: IP54, capable of IP64
Motor: 2 × 1500W
Speed ratio of reducer: 20
Rated load capacity: 125KG
Battery: 48V
Drive wheel diameter: 390mm
Battery voltage: 48V
Maximum climbing: 30 °
Maximum span: 100mm
