Dimensions: ≤ 1900 × 1500 × 1300 mm
Track width: 280 mm
Drive wheel diameter: 270 mm
Chassis weight (including 10% fuel and hydraulic oil): ＜ 1200kg
Rated load capacity: ＜ 600kg
Engine: 30.6Kw 2600rpm
Pump pressure/displacement: 25MPA/17cc
Driving speed: Turtle gear, top speed 5km/h
Rabbit gear top speed of 10km/h (poor steering on cement ground)
Ground clearance: 270 mm
Maximum obstacle crossing: 300 mm
Maximum span: 600 mm
Maximum wading depth: 300 mm
Maximum climbing angle: 32 ° (assuming friction coefficient)
Maximum lateral tilt stability angle: 25 ° (continuous operation less than 30 seconds)
Protection level: IP65 (can wade through water below 300mm)
Fuel tank capacity: 30L
Hydraulic oil tank capacity: 35L
Track material: high-quality rubber, embedded Kevlar fiber skeleton
