Size: 390 * 342 * 100 mm
Internal compartment size: 220 * 154 * 50 mm
Main materials: stainless steel/aluminum
Self weight: 7.5KG without battery
Drive wheel material: Aluminum
Track material: polyurethane, magnet composite
Drive wheel diameter: 75.6mm
Track width: 40mm
Traveling speed: 0-0.5 meters per second
Motor selection: DC brushless reduction motor
Chassis height: 3mm
Output torque: 16.8NM
Adsorption material: Magnetic conductive material
Rated power: 240W * 2
Protection level: IP54
Motor speed: 125RPM
Rated load: 10kg (90 ° vertical)
Climbing material: Magnetic conductive material (iron)
Ultimate load capacity: 60KG (measured at 85 ° C)
Ultimate load capacity: 10kg (180 ° ceiling)
Climbing angle: ≤ 90 °
Battery: Lithium battery DC24V10AH
Surface adaptability: Cylinder diameter>5 meters
Heat dissipation: dual fans
